10.1inch Android Display - Touch - Counter Model

Price:

€ 0,00


10.1inch Android Display - Touch - Counter Model

Product Code: EL-1027AIO-T-CD-OS6.0-RK3128

https://www.jamiepro.com/web/image/product.template/1854/image_1920?unique=4148faa

Screen size: 10.1inch, Screen type: Capacitive Touchscreen, LCD Panel Type: IPS Panel, LCD Panel resolution: 1280*800, Operation System: Rooted, Android 6.0 - RockChip RK3128, Quad Core Cortex A7, 1.2G, Interface - Connection portals: HDMI OUT, TF cardreader, LAN input for Internet connection - RJ45, 3.5mm Jack, Power Input DC 12V/1.5A, 2x USB 2.0, Network options: Wifi, LAN network, Bluetooth 4.0, Resolution Internal VideoPlayer: 1080P, Camera: 2.0MP front camera, Speakers: 2*2W, Mounting options: Counter Model, Start-Up: AutoStart by plug-in the power-adapter, Memory: RAM 1GB - Internal Memory: 16GB

Including:
EU Power Adapter

Installation of your software:
Install your own software (or from your client) by USB Stick. Most public software APK files you can download from websites like www.apkmirror.com.
Note: this is a rooted industrial Android screen, which means the Google Playstore is mostly not working in many regions. Please install an other Store if needed.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days


Android Counter Display

Our Android Displays are commercial models, specially designed and to use in a retail environment, online digital signage screens, info touch kiosk, etcetera.

The Android has a standard some programm apps installed, like a browser, google play store, explorer, and some extra apps.

You can install your own application on it. For instance a digital signage app or kiosk web app, webstore, etcetera.

We can also provide and help you with some retail app solutions, to help you to start your project. Find more about these apps at the software section.

These Android Displays have the following features:

  • - Touchscreen & Non-Touchscreen
  • - ROOTED ANDROID 6.0 software version
  • - WIFI network
  • - LAN (RJ45) input socket for a cable network connection (not for all models)
  • - 3G-4G connection via USB SIM dongle (optional, not included)

  • NOTE:
    Google Play store is not always working in some regions, but do not be afraid: most of the times you do not need this store. You just can install your own/clients (signage) APK by USB Stick or download it from a website and install it. Quiet often, you can download APK files from www.apkmirror.com or www.apkpure.com or ask your client for the APK needed to install.
    The benefit of not using the Google Playstore: you are not being watched by Google and Google will not get your userdata which you do not want to share with them anyway.

    PS: if you really need Google Playstore, we can check if it is possible, but only for larger order quantites.





How does it work?

Watch this video to have an more detailed explanation how these Android screens work.

NEW: RFID reader in android counter models 13.3 / 15.6 / 17.3 for scanning RFID tags and keys!




List of Features

easy setup and plug and play!
Auto Start when plug in the power adapter


Rooted Android 6.0 / Chip RK3128 / RAM 1GB-IM 16GB / CPU Quad core cortex A7, 1.2G

Capacitive Touch


10" IPS LCD panel 1280x800 pixels (16:10 ratio)


Internal HD videoplayer 1080P


WIFI, Bluetooth, LAN optional 3G


TF cardreader and 1x USB portal


Internal Speakers


3.5mm Jack Output


Thin Closed Frame Plastic Housing


Color housing standard Black, Optional white.


5V Power adapter with 3 meter long cable


24/7 usage


Timer Clock Function (optional app)



Purposes

can be used in many places

Digital Signage Display




Built-in ShopDisplays




Advertisement Display




Shelf-edge Display



CounterDisplay



USAGE:

Plug in the power adapter, and immediately the Android display will turn on (no need to push a ON-OFF button).

You can hide the top and bottom bar in the Settings menu.

Install your software easily and lets play!


OPTIONAL:

- with or without internal battery

- LAN converter box, to connect to the portal at the backside.


MORE SPECS:

see SPECIFICATIONS TAB or download the specification sheet in the DOWNLOAD TAB, above.




Operation System Android 6.0 - Rockchip RK3128 or Rooted or Quad Core Cortex A7, 1.2G
Interface - Connection portals HDMI OUT or TF cardreader or LAN input for Internetconnection - RJ45 or 3.5mm Jack or Power Input DC 12V/1.5A or 2x USB 2.0
Network options Wifi or LAN network or Bluetooth 4.0
Screen size 10.1inch
Screen type Touchscreen - Capacitive
LCD Panel Type IPS Panel
LCD Panel resolution 1280*800
Resolution Internal VideoPlayer 1080P
Start-Up AutoStart by plug-in the power-adapter
Speakers 2*2W
Mounting options Counter Model
Memory RAM 1GB - Internal Memory 16GB
Camera 2.0MP front camera
Download
EL-1027AIO-T-CD-10.1inch-Android-Display-Non-Touch-Counter-Picture.zip
Download
EL-1027AIO-T-CD-10.1inch-Android-Display-Touch-Counter-Specifications.pdf
Download
