13.3inch Android Display - Non Touch - Counter Model

Price:

€ 0,00


13.3inch Android Display - Non Touch - Counter Model

Product Code: EL-1313AIO-CD-OS9.0-RK3399

https://www.jamiepro.com/web/image/product.template/1855/image_1920?unique=29925db

Screen type: Non-Touchscreen, Screen size: 13.3inch, Operation System: Quad Core Cortex A53, Dual Core A72, Android 9.0 - RockChip RK3399, Housing type: Counter Model, LCD Panel resolution: 1920*1080, LCD Panel Type: IPS Panel, Ratio: 16:9, Interface - Connection portals: HDMI OUT, TF cardreader, USB Portal, USB for serial port, Power Input DC 12V/2A, LAN input for Internet connection - RJ45, Micro USB Portal, 3.5mm Jack, Network options: Wifi, LAN/WLAN, Bluetooth 4.0, Mounting options: Counter Model, Memory: RAM 2GB - Internal Memory 16GB, Start-Up: AutoStart by plug-in the power-adapter, Usage: 24/7, Speakers: 2*1W, Camera: 5.0MP front camera, PowerAdapter: AC/DC 12V/2A

Including:
EU Power Adapter

Installation of your software:
Install your own software (or from your client) by USB Stick. Most public software APK files you can download from websites like www.apkmirror.com.
Note: this is a rooted industrial Android screen, which means the Google Playstore is mostly not working in many regions. Please install another Store if needed.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Odoo CMS - a big picture

Android Counter Display

Our Android Displays are commercial models, specially designed and to use in a retail environment, online digital signage screens, info touch kiosk, etcetera.

The Android has a standard some programm apps installed, like a browser, google play store, explorer, and some extra apps.

You can install your own application on it. For instance a digital signage app or kiosk web app, webstore, etcetera.

We can also provide and help you with some retail app solutions, to help you to start your project. Find more about these apps at the software section.

These Android Displays have the following features:

  • - Touchscreen & Non-Touchscreen
  • - ROOTED ANDROID 9.0 software version
  • - WIFI network
  • - LAN (RJ45) input socket for a cable network connection (not for all models)
  • - 3G-4G connection via USB SIM dongle (optional, not included)

This desk-model shape is available in: 7 / 10.1 / 13.3 / 15.6 / 17.3 inch sizes.

NOTE:
Google Play store is not always working in some regions, but do not be afraid: most of the times you do not need this store. You just can install your own/clients (signage) APK by USB Stick or download it from a website and install it. Quiet often, you can download APK files from www.apkmirror.com or www.apkpure.com or ask your client for the APK needed to install.
The benefit of not using the Google Playstore: you are not being watched by Google and Google will not get your userdata which you do not want to share with them anyway.

PS: if you really need Google Playstore, we can check if it is possible, but only for larger order quantites.




How does it work?

Watch this video to have an more detailed explanation how these Android screens work.



NEW: RFID reader in android counter models 13.3 / 15.6 / 17.3 for scanning RFID tags and keys!


List of Features

easy setup and plug and play!
Auto Start when plug in the power adapter


Rooted Android 9.0 / Chip RK3399


Non Touch


13.3" IPS LCD panel 1920x1080 pixels (16:9 ratio)


Internal HD videoplayer 1080P


WIFI, Bluetooth and LAN optional 3G


TF cardreader and 1x USB portal


Internal Speakers


3.5mm Jack Output


Thin Closed Frame Plastic Housing


Color housing standard Black, Optional white.


12V Power adapter with 3 meter long cable


24/7 usage


Timer Clock Function (optional app)


Purposes

can be used in many places

Digital Signage Display




Built-in ShopDisplays




Advertisement Display




Shelf-edge Display



CounterDisplay



USAGE:

Plug in the power adapter, and immediately the Android display will turn on (no need to push a ON-OFF button).

You can hide the top and bottom bar in the Settings menu.

Install your software easily and lets play!


OPTIONAL:

- with or without internal battery

- LAN converter box, to connect to the portal at the backside.


MORE SPECS:

see SPECIFICATIONS TAB or download the specification sheet in the DOWNLOAD TAB, above.



Operation System Dual Core A72 or Quad Core A53 or Rooted or Android 9.0 - RockChip RK3399
Interface - Connection portals HDMI OUT or TF cardreader or USB Portal or USB for serial port or Power Input DC 12V/2A or LAN input for Internetconnection - RJ45 or Micro USB Portal or 3.5mm Jack
Network options Wifi or LAN/WLAN or Bluetooth 4.0
Screen size 13.3inch
Screen type Non-Touchscreen
LCD Panel Type IPS Panel
LCD Panel resolution 1920*1080
Ratio 16:9
Housing type Counter Model
Start-Up AutoStart by plug-in the power-adapter
Usage 24/7
Speakers 2*1W
Mounting options Counter Model
Memory RAM 2GB - Internal Memory: 16GB
Camera 5.0MP front camera
PowerAdapter AC/DC 12V/2A
Download
EL-1313AIO-CD-13.3inch-Android-Display-Non-Touch-Counter-Pictures.zip
Download
EL-1313AIO-CD-13.3inch-Android-Display-Non-Touch-Counter-Specifications.pdf
Download
