14inch Android Display - Non Touch - Counter Model - MOQ = 500pcs
Product Code: EL-1412AIO-CD-OS8.1-RK3288
Screen type: Non-Touchscreen, Screen size: 14inch, Operation System: Quad Core Cortex A17, 1.8G, Android 8.1 - RockChip RK3288, Housing type: Counter Model, LCD Panel resolution: 1920*1080, LCD Panel Type: IPS Panel, Ratio: 16:9, Interface - Connection portals: HDMI OUT, TF cardreader, USB Portal, USB for serial port, Power Input DC 12V/2A, LAN input for Internet connection - RJ45, Micro USB Portal, 3.5mm Jack, Network options: Wifi, LAN/WLAN, Bluetooth 4.0, Mounting options: Counter Model, Memory: RAM 2GB - Internal Memory 16GB, Start-Up: AutoStart by plug-in the power-adapter, Usage: 24/7, Speakers: 2*1W, Camera: 5.0MP front camera, PowerAdapter: AC/DC 12V/2A
Including:
EU Power Adapter
Installation of your software:
Install your own software (or from your client) by USB Stick. Most public software APK files you can download from websites like www.apkmirror.com.
Note: this is a rooted industrial Android screen, which means the Google Playstore is mostly not working in many regions. Please install another Store if needed.
Android Counter Display
Our Android Displays are commercial models, specially designed and to use in a retail environment, online digital signage screens, info touch kiosk, etcetera.
The Android has a standard some programm apps installed, like a browser, google play store, explorer, and some extra apps.
You can install your own application on it. For instance a digital signage app or kiosk web app, webstore, etcetera.
We can also provide and help you with some retail app solutions, to help you to start your project. Find more about these apps at the software section.
These Android Displays have the following features:
- - Touchscreen & Non-Touchscreen
- - ROOTED ANDROID 8.1 software version
- - WIFI network
- - LAN (RJ45) input socket for a cable network connection (not for all models)
- - 3G-4G connection via USB SIM dongle (optional, not included)
This desk-model shape is available in: 7 / 10.1 / 13.3 / 15.6 / 17.3 inch sizes.
NOTE:
Google
Play store is not always working in some regions, but do not be afraid:
most of the times you do not need this store.
You just can install your own/clients (signage) APK by USB Stick or
download it from a website and install it.
Quiet often, you can download APK files from www.apkmirror.com or
www.apkpure.com or ask your client for the APK needed to install.
The
benefit of not using the Google Playstore: you are not being watched by
Google and Google will not get your userdata which you do not want to
share with them anyway.
PS: if you really need Google Playstore, we can check if it is possible, but only for larger order quantites.
How does it work?
Watch this video to have an more detailed explanation how these Android screens work.
NEW: RFID reader in android counter models 13.3 / 15.6 / 17.3 for scanning RFID tags and keys!
List of Features
easy setup and plug and play!
Rooted Android 8.1 / Chip RK3288
Non Touch
WIFI, Bluetooth, optional LAN and 3G
TF cardreader and 1x USB portal
Internal Speakers
3.5mm Jack Output
Thin Closed Frame Plastic Housing
Color housing standard Black, Optional white.
12V Power adapter with 3 meter long cable
24/7 usage
Timer Clock Function (optional app)
Purposes
can be used in many places
Digital Signage Display
Built-in ShopDisplays
Advertisement Display
Shelf-edge Display
CounterDisplay
USAGE:
Plug in the power adapter, and immediately the Android display will turn on (no need to push a ON-OFF button).
You can hide the top and bottom bar in the Settings menu.
Install your software easily and lets play!
OPTIONAL:
- with or without internal battery
- LAN converter box, to connect to the portal at the backside.
MORE SPECS:
see SPECIFICATIONS TAB or download the specification sheet in the DOWNLOAD TAB, above.
| Operation System | Quad Core Cortex A17, 1.8G or Android 8.1 - RockChip RK3288 |
| Interface - Connection portals | HDMI OUT or TF cardreader or USB Portal or USB for serial port or Power Input DC 12V/2A or LAN input for Internetconnection - RJ45 or Micro USB Portal or 3.5mm Jack |
| Network options | Wifi or LAN/WLAN or Bluetooth 4.0 |
| Screen size | 14inch |
| Screen type | Non-Touchscreen |
| LCD Panel Type | IPS Panel |
| LCD Panel resolution | 1920*1080 |
| Ratio | 16:9 |
| Housing type | Counter Model |
| Start-Up | AutoStart by plug-in the power-adapter |
| Usage | 24/7 |
| Speakers | 2*1W |
| Mounting options | Counter Model |
| Memory | RAM 2GB - Internal Memory: 16GB |
| Camera | 5.0MP front camera |
| PowerAdapter | AC/DC 12V/2A |
