11.6inch Android Display - TouchScreen

Price:

€ 216,00


11.6inch Android Display - TouchScreen

Product Code: EL-1172AIO-T-OS8.1-RK3288

https://www.jamiepro.com/web/image/product.template/1482/image_1920?unique=4829a70

Screen type: Touchscreen - Capacitive, Operation System: Octa Core Cortex A53, 1.5G, Rooted, Android 8.1 - RockChip RK3288, Screen size: 11.6inch, Housing type: Closed plastic housing, LCD Panel resolution: 1366*768, Ratio: 16:9, LCD Panel Type: IPS Panel, LCD Panel resolution: 1920*1080, Interface - Connection portals: PoE (power over ethernet), HDMI OUT, SD/MMC Cardreader, USB Portal, LAN input for Internetconnection - RJ45, Micro USB Portal, 3.5mm Jack, Network options: Wi-Fi, LAN/WLAN, Bluetooth 4.0,Mobile Network (3G-4G) - Optional by USB SIM Dongle, Mounting options: VESA 75x75mm - screwholes 4M, Memory: RAM 2GB - Internal Memory: 16GB, Speakers: Internal Speakers: 2x 1.5W/8Ohm, PowerAdapter: AC/DC 12V/2A

Including:
EU Power Adapter

Installation of your software:
Install your own software (or from your client) by USB Stick. Most public software APK files you can download from websites like www.apkmirror.com.
Note: this is a rooted industrial Android screen, which means the Google Playstore is mostly not working in many regions. Please install an other Store if needed.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Android Display

Our Android Displays are commercial models, specially designed and to use in a retail environment, online digital signage screens, info touch kiosk, etcetera.

The Android has a standard some programm apps installed, like a browser, google play store, explorer, and some extra apps.

You can install your own application on it. For instance a digital signage app or kiosk web app, webstore, etcetera.

We can also provide and help you with some retail app solutions, to help you to start your project. Find more about these apps at the software section.

These Android Displays have the following features:

  • - Touchscreen & Non-Touchscreen
  • - ROOTED ANDROID 8.1 software version
  • - WIFI network
  • - LAN (RJ45) input socket for a cable network connection (not included)
  • - 3G-4G connection via USB SIM dongle (optional, not included)

This desk-model shape is available in: 10.1 / 13.3 /  14 / 15.6 / 18.5 / 21.5 / 24 / 27 / 32 / 43 / 55 inch sizes.


NOTE:
Google Play store is not always working in some regions, but do not be afraid: most of the times you do not need this store. You just can install your own/clients (signage) APK by USB Stick or download it from a website and install it. Quiet often, you can download APK files from www.apkmirror.com or www.apkpure.com or ask your client for the APK needed to install.
The benefit of not using the Google Playstore: you are not being watched by Google and Google will not get your userdata which you do not want to share with them anyway.

PS: if you really need Google Playstore, we can check if it is possible, but only for larger order quantites.





How does it work?

Watch this video to have an more detailed explanation how these Android screens work.


List of Features

easy setup and plug and play!
Auto Start when plug in the power adapter


Rooted Android 8.1 / Chip RK3288 / RAM 2GB-IM 16GB / CPU Quad core cortex A53, 1.5G

Capacitive TouchScreen (10 points), optional NON-touchscreen.

11.6" IPS LCD panel 1366x768 pixels (16:9 ratio)


Internal HD videoplayer 1080P


WIFI, Bluetooth, optional LAN and 3G


SD cardreader and 1x USB portal


Internal Speakers


3.5mm Jack Output


Thin Closed Frame Plastic Housing


Color housing standard Black, Optional white.


12V Power adapter with 3 meter long cable


24/7 usage


Timer Clock Function (optional app)


Purposes

can be used in many places

Digital Signage Display




Built-in ShopDisplays




Advertisement Display




Shelf-edge Display



CounterDisplay



USAGE:

Plug in the power adapter, and immediately the Android display will turn on (no need to push a ON-OFF button).

You can hide the top and bottom bar in the Settings menu.

Install your software easily and lets play!


OPTIONAL:

- with or without internal battery

- LAN converter box, to connect to the portal at the backside.


MORE SPECS:

see SPECIFICATIONS TAB or download the specification sheet in the DOWNLOAD TAB, above.



Optional Features Software Systems for Digital Signage & Kiosks or 3G Network via USB-SimCard Dongle
Operation System Octa Core Cortex A53, 1.5G or Rooted or Android 8.1 - RockChip RK3288
Interface - Connection portals PoE (power over ethernet) or HDMI OUT or SD/MMC Cardreader or USB Portal or LAN input for Internetconnection - RJ45 or Micro USB Portal or 3.5mm Jack
Network options Wi-Fi or LAN/WLAN or Bluetooth 4.0 or Mobile Network (3G-4G) - Optional by USB SIM Dongle
Screen size 11.6inch
Screen type Touchscreen - Capacitive
LCD Panel Type IPS Panel
LCD Panel resolution 1920*1080 , 1366*768
Ratio 16:9
Housing type Closed plastic housing
Speakers Internal Speakers: 2x 1.5W/8Ohm
Mounting options VESA 75x75mm - screwholes 4M
Memory RAM 2GB - Internal Memory: 16GB
PowerAdapter AC/DC 12V/2A
EL-1172AIO-T-11,6inch-Android-TouchScreen-Display-Tablet-Specifications.pdf
Download
EL-1172AIO-T-BAT-11,6inch-Android-TouchScreen-Display-Tablet-Pictures.zip
Download
EL-1172AIO-T-BAT-11.6inch-Android-TouchScreen-Display-Tablet-Drawing.pdf
Download
