Diagonal Size 65" Type Edge LED BLU Resolution 3840*2160 (4K UHD) Pixel Pitch(mm) 0.372 x 0.372 Active Display Area(mm) 1428.48 (H) x 803.52 (V) Brightness(Typ.) 350 nit Contrast Ratio 4000:1 Viewing Angle(H/V) 178/178 Response Time(G-to-G) 8ms(Typ.) Display Colors 16.7M(True Display) 1.07B(Ditherd 10bit) Color Gamut 92% (DCI-P3, CIE 1976) Operation Hour 16/7 Haze 2% Display Dynamic C/R MEGA H-Scanning Frequency 30 ~ 81kHZ V-Scanning Frequency 48 ~ 75HZ Maximum Pixel Frequency 594MHz Sound Speaker Type Built in Speaker(10W + 10W) Connectivity Input RGB DVI-D Video HDMI 2.0 (2) HDCP HDCP 2.2 Audio Stereo Mini Jack, DVI/HDMI/Audio(Common) USB USB 2.0 x 2 Output Audio Stereo Mini Jack External Control RS232C(in/out) thru stereo jack, RJ45 External Sensor IR Power Type Internal Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz Power Consumption Max[W/h] 181.5 Typical[W/h] 128 Rating[W/h] 165 BTU(Max) 618.9 Sleep mode 0.5 Mechanical Specification Dimension (mm) Set 1453.9 x 831.0 x 46.3 Package 1611 x 973 x 185 Weight (kg) Set 24.9 Package 33.3 VESA Mount (mm) 400 X 400 Stand Type No Bezel Width (mm) 9.2mm(U/L/R), 11.2mm(B) Operation Operating Temperature 0 ℃ ~ 40 ℃ Humidity 10 % ~ 80 % Feature Key Features UHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0 Orientation N/A Remote Control N/A Special Features H/W: Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), IP5x, Wi-Fi/BT S/W: Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting) Internal Player Processor Coretex A72 1.7GHz Quad-Core CPU On-Chip Cache Memory L1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB Clock Speed 1.7GHz Main Memory Interface 2.5GB LPDDR4 1.5GHz 64bit Graphics Graphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.) Storage (FDM) 8GB (3.88GB Occupied by O/S, 4.12GB Available) Multimedia *Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG IO Ports USB 2.0 Operating System Tizen 4.0 (VDLinux) Certification Safety 60950-1 EMC Class B Security 802.1x(WPA2 Enterprise): EAP-TLS, EAP-TTLS, EAP-PEAP Accessory Included Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries Optional Stand No Mount WMN4277SE
