10inch Touch Monitor - Thin - HDMI IN - 400/600nit
Product Code: EL-101A-T-MON-HDMI-400nit
Screen size: 10.1inch, Screen type: Touchscreen - Capacitive, Screen type: 10 points touch, LCD Panel Type: IPS Panel, LCD Panel resolution: 1280*800, Ratio: 16:10, Interface - Connection portals: HDMI MINI, Interface - Connection portals: USB-C for touchscreen, Interface - Connection portals: USB-C for power input, Frame Housing type: Closed plastic housing, Frame Housing type: Ultra Thin housing with small bezel at frontside, Frame Housing type: Pushbuttons on top (On-OFF & VolumeButtons can be disabled/removed), Start-Up: AutoStart when plug-in the power cable, Brightness: 400nit, Brightness: Optional: 600nit +€10, CPU: Realtek RTD2555T, ViewAngles: 85/85/85/85
List of Features
easy setup and plug and play!
Auto Start
HDMI IN-mini for Monitor function
IPS Panel 1280x800 pixels - High Resolution
16:10 ratio
Capacitive TouchScreen + USB-C Connector to connect to external player.
Internal Speakers (8Ω*1W*2)
Plastic Housing
24 hours a day
USB-C connection cable included
Black Plastic Housing, optional white housing.
Purposes
can be used in retail, musea, public enviroments, restaurant, etcetera.
Built-in ShopDisplays
Advertisement Display
Digital Signage Display
USAGE:
This Monitor Capacitive Touchscreen with high resolution IPS Panel. Add an external player and connect it with a HDMI cable. For the touch function you need to connect the USB cable into your external player. It works autostart; plug in the power and the Monitor will start by itself. There is also an ON-OFF switch you can use. Note: these buttons can be disabled/removed on volume orders.
| Screen type | Touchscreen - Capacitive or 10 points touch |
| Interface - Connection portals | HDMI MINI or USB-C for touchscreen or USB-C for power input |
| Frame Housing type | Closed plastic housing or Ultra Thin housing with small bezel at frontside or Pushbuttons on top (On-OFF & VolumeButtons can be disabled/removed) |
| Brightness | 400nit or Optional: 600nit +€10 |
| Screen size | 10.1inch |
| LCD Panel Type | IPS Panel |
| LCD Panel resolution | 1280*800 |
| Ratio | 16:10 |
| Start-Up | AutoStart when plug-in the power cable |
| CPU | Realtek RTD2555T |
| ViewAngles | 85/85/85/85 |
List of Features
easy setup and plug and play!
Auto Start
HDMI IN-mini for Monitor function
IPS Panel 1280x800 pixels - High Resolution
16:10 ratio
Capacitive TouchScreen + USB-C Connector to connect to external player.
Internal Speakers (8Ω*1W*2)
Plastic Housing
24 hours a day
USB-C connection cable included
Black Plastic Housing, optional white housing.
Purposes
can be used in retail, musea, public enviroments, restaurant, etcetera.
Built-in ShopDisplays
Advertisement Display
Digital Signage Display
USAGE:
This Monitor Capacitive Touchscreen with high resolution IPS Panel. Add an external player and connect it with a HDMI cable. For the touch function you need to connect the USB cable into your external player. It works autostart; plug in the power and the Monitor will start by itself. There is also an ON-OFF switch you can use. Note: these buttons can be disabled/removed on volume orders.
